Art Audio VP1
Opis
Art Audio VP1
All amplifying stages are triode and pure class ‘A’
Star Grounding system
Remote switching for short signal paths
Switchable low and high gain stages
6 inputs, 2 outputs, 2 tape monitors
The VP1 Mk II has an identical line section to the VPL but adds a 3-tube MM phono section with cathode followers
Black faceplate with a gold lettering and gold-plated control knobs
Type: Vacuum tube pure class ‘A’ preamplifier
Input Overload: Phono 80mV, Line 10V
Sensitivity( 1V out ): Phono 2.5mV into 47K ohms, Line 80mV into 220K ohms
Frequency Response: 20hz to 20Khz ( Phono ± 0.5 dB., Line ± 0.1 dB.
Distortion: Phono 0.05%, Line 0.02%
Frequency Response: 20Hz to 60kHz ± 0.3dB.
Noise: Phono 73dB., Line 82dB.
Output: 7V rms
Tube Complement:
VPL: 2 x 12AX7/CV4004
VP1: 5 x 12AX7
Dimensions: 18.25\” x 10.75\” (incl. terminals) x 4\” [ W x D x H ]
Weight: 21 lbs.
Warranty: 3 years parts and labor/90 days on tubes
